Volume pricing
- 1+ pcs$6.35
- 10+ pcs$5.99
- 100+ pcs$5.65
- 500+ pcs$5.33
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Nominal Gerilim
- 12VDC
- Bearing Type
- Ball
- Fabrika Tedarik Süresi
- 19 Weeks
- Boyut / Ölçü
- Square - 80mm Lx80mm H
- Operating Supply Voltage
- 12V
- Onay Kuruluşu
- cURus, TUV
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Depth
- 15mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yükseklik
- 80mm
- Fan Type
- Tubeaxial
- Akım Değeri
- 50mA
- Power Consumption
- 1.8W
- Kılıf / Paket
- Axial
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Power Rating
- 150mW
- Terminal
- 2 Wire Leads
- Seri
- OD8015
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Plastic
- Voltage Range
- 8V~16VDC
- Lifetime Temp
- 60000 Hrs @ 45°C
- Yayın Yılı
- 2011
- Current Rating Amps
- 0.050A
- Rpm
- 2500 RPM
- RoHS Durumu
- ROHS3 Compliant
- Static Pressure
- 0.070 in H2O (17.4 Pa)
- Noise
- 26.0 dB
