Volume pricing
- 1+ pcs$13.23
- 10+ pcs$12.49
- 100+ pcs$11.78
- 500+ pcs$11.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Genişlik
- 15.50mm
- Kurşunsuz
- Lead Free
- Onay Kuruluşu
- cURus, TUV
- Güç (Watt)
- 4.32W
- Max Power Dissipation
- 4.32W
- Kılıf / Paket
- Axial
- Akım Değeri
- 260mA
- Min. Çalışma Sıcaklığı
- 14°C
- Fan Type
- Tubeaxial
- Fabrika Tedarik Süresi
- 19 Weeks
- Bearing Type
- Ball
- Weight
- 0.111lb 50.35g
- Nominal Gerilim
- 12VDC
- Parça Durumu
- Active
- Boyut / Ölçü
- Square - 70mm Lx70mm H
- Static Pressure
- 0.260 in H2O (64.8 Pa)
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 5500 RPM
- Yayın Yılı
- 2010
- Current Rating Amps
- 0.260A
- Noise
- 44.5 dB
- Maks. Çalışma Sıcaklığı
- 158°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- OD7015
- Terminal
- 3 Wire Leads
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Lifetime Temp
- 70000 Hrs @ 40°C
- Özellikler
- Speed Sensor (Tach)
- Voltage Range
- 7V~13.2VDC
