Volume pricing
- 1+ pcs$10.29
- 10+ pcs$9.71
- 100+ pcs$9.16
- 500+ pcs$8.64
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Nominal Gerilim
- 24VDC
- Seri
- OD6015
- Boyut / Ölçü
- Square - 60mm Lx60mm H
- Ambalaj
- Box
- Fan Type
- Tubeaxial
- Uzunluk
- 60mm
- Güç (Watt)
- 1.2W
- Material Blade
- Polybutylene Terephthalate (PBT)
- Maks. Çalışma Sıcaklığı
- 176°C
- Yayın Yılı
- 2010
- Material Frame
- Polybutylene Terephthalate (PBT)
- Power Consumption
- 2.2W
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- Plastic
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Fabrika Tedarik Süresi
- 19 Weeks
- Genişlik
- 15.00mm
- Static Pressure
- 0.150 in H2O (37.3 Pa)
- Parça Durumu
- Active
- Onay Kuruluşu
- cURus, TUV
- Noise
- 33.0 dB
- Terminal
- 2 Wire Leads
- Operating Supply Voltage
- 24V
- Kurşunsuz
- Lead Free
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- Axial
- Material
- Plastic
- Bearing Type
- Ball
- Akım Değeri
- 150mA
- Lifetime Temp
- 60000 Hrs @ 40°C
- Current Rating Amps
- 0.050A
- Rpm
- 4500 RPM
- Weight
- 0.079lb 35.83g
- Özellikler
- Auto Restart
- Power Rating
- 1.2W
- Yükseklik
- 60mm
- Montaj
- Flanges
- Min. Çalışma Sıcaklığı
- -4°C
- Depth
- 15mm
