Volume pricing
- 1+ pcs$9.95
- 10+ pcs$9.39
- 100+ pcs$8.86
- 500+ pcs$8.36
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Min. Çalışma Sıcaklığı
- -4°C
- Yükseklik
- 40mm
- Terminal
- 3 Wire Leads
- Kılıf / Paket
- Axial
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Range
- 7V~14VDC
- Bearing Type
- Ball
- Akım Değeri
- 100mA
- Material
- Plastic
- Lifetime Temp
- 60000 Hrs @ 45°C
- Current Rating Amps
- 0.100A
- Life Hours
- 60000 hours
- Özellikler
- Locked Rotor Sensor
- Weight
- 30.000004g
- Rpm
- 7800 RPM
- Housing Material
- Plastic
- RoHS Durumu
- ROHS3 Compliant
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Genişlik
- 20.00mm
- Fabrika Tedarik Süresi
- 19 Weeks
- Parça Durumu
- Active
- Static Pressure
- 0.300 in H2O (74.7 Pa)
- Onay Kuruluşu
- cURus, TUV
- Noise
- 32.0 dB
- Nominal Gerilim
- 12VDC
- Seri
- OD4020
- Boyut / Ölçü
- Square - 40mm Lx40mm H
- Fan Type
- Tubeaxial
- Uzunluk
- 40mm
- Maks. Çalışma Sıcaklığı
- 176°C
- Yayın Yılı
- 2011
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
