Volume pricing
- 1+ pcs$11.19
- 10+ pcs$10.56
- 100+ pcs$9.96
- 500+ pcs$9.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Boyut / Ölçü
- Square - 40mm Lx40mm H
- Parça Durumu
- Active
- Weight
- 0.053lb 24.04g
- Bearing Type
- Ball
- Nominal Gerilim
- 5VDC
- Fabrika Tedarik Süresi
- 19 Weeks
- Fan Type
- Tubeaxial
- Min. Çalışma Sıcaklığı
- 14°C
- Akım Değeri
- 150mA
- Max Power Dissipation
- 1.5W
- Onay Kuruluşu
- CE, cURus
- Güç (Watt)
- 1.5W
- Genişlik
- 15.00mm
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Material Frame
- Polybutylene Terephthalate (PBT)
- Voltage Range
- 4V~5.5VDC
- Lifetime Temp
- 70000 Hrs @ 40°C
- Material Blade
- Polybutylene Terephthalate (PBT)
- Terminal
- 2 Wire Leads
- Seri
- OD4015
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Maks. Çalışma Sıcaklığı
- 158°C
- Noise
- 26.0 dB
- Current Rating Amps
- 0.150A
- Yayın Yılı
- 2010
- Rpm
- 6000 RPM
- RoHS Durumu
- ROHS3 Compliant
- Static Pressure
- 0.160 in H2O (39.8 Pa)
