Volume pricing
- 1+ pcs$11.20
- 10+ pcs$10.57
- 100+ pcs$9.97
- 500+ pcs$9.41
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 19 Weeks
- Bearing Type
- Ball
- Nominal Gerilim
- 24VDC
- Parça Durumu
- Active
- Operating Supply Voltage
- 24V
- Boyut / Ölçü
- Square - 40mm Lx40mm H
- Depth
- 10mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yükseklik
- 40mm
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Kurşunsuz
- Lead Free
- Onay Kuruluşu
- cURus, TUV
- Kılıf / Paket
- Axial
- Power Consumption
- 2.16W
- Akım Değeri
- 60mA
- Fan Type
- Tubeaxial
- Housing Material
- Plastic
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- 3 Wire Leads
- Seri
- OD4010
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Lifetime Temp
- 60000 Hrs @ 45°C
- Özellikler
- Speed Sensor (Tach)
- Montaj
- Flanges
- Voltage Range
- 10V~27VDC
- Rpm
- 6000 RPM
- RoHS Durumu
- ROHS3 Compliant
- Static Pressure
- 0.100 in H2O (24.9 Pa)
- Yayın Yılı
- 2010
- Current Rating Amps
- 0.060A
- Noise
- 25.0 dB
