Volume pricing
- 1+ pcs$12.19
- 10+ pcs$11.50
- 100+ pcs$10.85
- 500+ pcs$10.24
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Boyut / Ölçü
- Square - 40mm Lx40mm H
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 19 Weeks
- Nominal Gerilim
- 12VDC
- Bearing Type
- Ball
- Weight
- 19.999993g
- Life Hours
- 60000 hours
- Min. Çalışma Sıcaklığı
- -4°C
- Fan Type
- Tubeaxial
- Kılıf / Paket
- Axial
- Akım Değeri
- 90mA
- Uzunluk
- 40mm
- Onay Kuruluşu
- cURus, TUV
- Yükseklik
- 40mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Material
- Plastic
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Genişlik
- 10.50mm
- Voltage Range
- 7V~14VDC
- Lifetime Temp
- 60000 Hrs @ 45°C
- Özellikler
- Locked Rotor Sensor
- Seri
- OD4010
- Terminal
- 3 Wire Leads
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Plastic
- Noise
- 25.0 dB
- Maks. Çalışma Sıcaklığı
- 176°C
- Yayın Yılı
- 2010
- Current Rating Amps
- 0.090A
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 6000 RPM
- Static Pressure
- 0.100 in H2O (24.9 Pa)
