Specifications
- Maks. Çalışma Sıcaklığı
- 176°C
- Noise
- 25.0 dB
- Rpm
- 6000 RPM
- RoHS Durumu
- ROHS3 Compliant
- Static Pressure
- 0.100 in H2O (24.9 Pa)
- Current Rating Amps
- 0.090A
- Yayın Yılı
- 2010
- Özellikler
- Speed Sensor (Tach)
- Lifetime Temp
- 60000 Hrs @ 45°C
- Voltage Range
- 7V~14VDC
- Housing Material
- Plastic
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Terminal
- 3 Wire Leads
- Seri
- OD4010
- Akım Değeri
- 90mA
- Kılıf / Paket
- Axial
- Power Consumption
- 1.2W
- Fan Type
- Tubeaxial
- Min. Çalışma Sıcaklığı
- -4°C
- Genişlik
- 10.50mm
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Kurşunsuz
- Lead Free
- Yükseklik
- 40mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Material
- Plastic
- Depth
- 10mm
- Onay Kuruluşu
- cURus, TUV
- Uzunluk
- 40mm
- Operating Supply Voltage
- 12V
- Boyut / Ölçü
- Square - 40mm Lx40mm H
- Bearing Type
- Ball
- Weight
- 19.999993g
- Nominal Gerilim
- 12VDC
- Fabrika Tedarik Süresi
- 19 Weeks
- Parça Durumu
- Active
