Volume pricing
- 1+ pcs$9.20
- 10+ pcs$8.68
- 100+ pcs$8.19
- 500+ pcs$7.72
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 19 Weeks
- Nominal Gerilim
- 12VDC
- Bearing Type
- Ball
- Boyut / Ölçü
- Square - 30mm Lx30mm H
- Operating Supply Voltage
- 12V
- Onay Kuruluşu
- cURus, TUV
- Yükseklik
- 30mm
- Depth
- 10mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Fan Type
- Tubeaxial
- Power Consumption
- 1.4W
- Kılıf / Paket
- Axial
- Akım Değeri
- 100mA
- Seri
- OD3010
- Terminal
- 2 Wire Leads
- Power Rating
- 100mW
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Plastic
- Voltage Range
- 8V~17VDC
- Lifetime Temp
- 60000 Hrs @ 45°C
- Montaj
- Flanges
- Current Rating Amps
- 0.100A
- Ambalaj
- Box
- Static Pressure
- 0.200 in H2O (49.8 Pa)
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 11000 RPM
- Noise
- 32.0 dB
