Volume pricing
- 1+ pcs$12.21
- 10+ pcs$11.52
- 100+ pcs$10.87
- 500+ pcs$10.25
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Range
- 6V~16VDC
- Lifetime Temp
- 60000 Hrs @ 45°C
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Terminal
- 2 Wire Leads
- Seri
- OD2510
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Maks. Çalışma Sıcaklığı
- 158°C
- Noise
- 16.0 dB
- Current Rating Amps
- 0.040A
- Yayın Yılı
- 2010
- Static Pressure
- 0.120 in H2O (29.9 Pa)
- Rpm
- 8000 RPM
- RoHS Durumu
- ROHS3 Compliant
- Boyut / Ölçü
- Square - 25.5mm Lx25.5mm H
- Parça Durumu
- Active
- Bearing Type
- Ball
- Nominal Gerilim
- 12VDC
- Fabrika Tedarik Süresi
- 19 Weeks
- Fan Type
- Tubeaxial
- Min. Çalışma Sıcaklığı
- -13°C
- Life Hours
- 60000 hours
- Akım Değeri
- 40mA
- Kılıf / Paket
- Axial
- Onay Kuruluşu
- cURus, TUV
- Uzunluk
- 25.5mm
- Genişlik
- 10.00mm
- Çalışma Sıcaklığı
- -13~158°F -25°C~70°C
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yükseklik
- 25.5mm
