Specifications
- Onay Kuruluşu
- cURus, TUV
- Çalışma Sıcaklığı
- -4~167°F -20°C~75°C
- Yükseklik
- 150mm
- Material Frame
- Aluminum
- Fan Type
- Tubeaxial
- Akım Değeri
- 970mA
- Kılıf / Paket
- Axial
- Parça Durumu
- Active
- Bearing Type
- Ball
- Weight
- 820.095005g
- Nominal Gerilim
- 24VDC
- Fabrika Tedarik Süresi
- 17 Weeks
- Boyut / Ölçü
- Rectangular/Rounded - 172mm Lx150mm H
- Yayın Yılı
- 2010
- Current Rating Amps
- 0.970A
- Static Pressure
- 0.790 in H2O (196.8 Pa)
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 3300 RPM
- Noise
- 52.0 dB
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Seri
- OD172S
- Terminal
- 3 Wire Leads
- Housing Material
- Aluminium
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Range
- 15V~28VDC
- Özellikler
- Auto Restart, Locked Rotor Sensor
- Lifetime Temp
- 40000 Hrs @ 60°C
