Volume pricing
- 1+ pcs$25.65
- 10+ pcs$24.20
- 100+ pcs$22.83
- 500+ pcs$21.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2011
- Current Rating Amps
- 0.300A
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 2600 RPM
- Static Pressure
- 0.300 in H2O (74.7 Pa)
- Noise
- 41.0 dB
- Maks. Çalışma Sıcaklığı
- 158°C
- Seri
- OD1238
- Terminal
- 2 Wire Leads
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Plastic
- Voltage Range
- 36V~72VDC
- Lifetime Temp
- 65000 Hrs @ 45°C
- Uzunluk
- 120mm
- Güç (Watt)
- 14.4W
- Onay Kuruluşu
- cURus, TUV
- Max Power Dissipation
- 14.4W
- Material
- Plastic
- Depth
- 38mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yükseklik
- 120mm
- Kurşunsuz
- Lead Free
- Genişlik
- 38.00mm
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Min. Çalışma Sıcaklığı
- -4°C
- Fan Type
- Tubeaxial
- Kılıf / Paket
- Axial
- Akım Değeri
- 300mA
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 18 Weeks
- Nominal Gerilim
- 60VDC
- Bearing Type
- Ball
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Operating Supply Voltage
- 60V
