Volume pricing
- 1+ pcs$35.32
- 10+ pcs$33.32
- 100+ pcs$31.43
- 500+ pcs$29.65
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 38mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yükseklik
- 120mm
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Onay Kuruluşu
- cURus, TUV
- Güç (Watt)
- 48W
- Max Power Dissipation
- 48W
- Kılıf / Paket
- Axial
- Akım Değeri
- 1A
- Fan Type
- Tubeaxial
- Fabrika Tedarik Süresi
- 18 Weeks
- Bearing Type
- Ball
- Weight
- 353.000012g
- Nominal Gerilim
- 48VDC
- Parça Durumu
- Active
- Operating Supply Voltage
- 48V
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Rpm
- 5000 RPM
- RoHS Durumu
- ROHS3 Compliant
- Static Pressure
- 1.350 in H2O (336.3 Pa)
- Yayın Yılı
- 2010
- Noise
- 65.0 dB
- Housing Material
- Plastic
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- 4 Wire Leads
- Seri
- OD1238 VA
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Lifetime Temp
- 65000 Hrs @ 45°C
- Özellikler
- Auto Restart, PWM Control, Speed Sensor (Tach)
- Voltage Range
- 24V~55VDC
