Volume pricing
- 1+ pcs$24.48
- 10+ pcs$23.10
- 100+ pcs$21.79
- 500+ pcs$20.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- Speed Sensor (Tach)
- Lifetime Temp
- 65000 Hrs @ 45°C
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Seri
- OD1238
- Terminal
- 3 Wire Leads
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Maks. Çalışma Sıcaklığı
- 158°C
- Noise
- 43.0 dB
- Yayın Yılı
- 2012
- Current Rating Amps
- 0.320A
- Static Pressure
- 0.240 in H2O (59.8 Pa)
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 2800 RPM
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Operating Supply Voltage
- 24V
- Parça Durumu
- Active
- Bearing Type
- Ball
- Weight
- 329.999987g
- Nominal Gerilim
- 24VDC
- Fabrika Tedarik Süresi
- 19 Weeks
- Fan Type
- Tubeaxial
- Min. Çalışma Sıcaklığı
- 14°C
- Akım Değeri
- 320mA
- Kılıf / Paket
- Axial
- Power Consumption
- 7W
- Max Power Dissipation
- 7W
- Onay Kuruluşu
- cURus, TUV
- Güç (Watt)
- 7W
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Genişlik
- 38.50mm
- Kurşunsuz
- Lead Free
- Yükseklik
- 120mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Depth
- 38.5mm
- Material
- Plastic
