Specifications
- Fabrika Tedarik Süresi
- 19 Weeks
- Nominal Gerilim
- 24VDC
- Bearing Type
- Ball
- Parça Durumu
- Active
- Operating Supply Voltage
- 24V
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Yükseklik
- 120mm
- Material
- Plastic
- Depth
- 38.5mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Onay Kuruluşu
- cURus, TUV
- Max Power Dissipation
- 7W
- Power Consumption
- 7W
- Kılıf / Paket
- Axial
- Akım Değeri
- 320mA
- Fan Type
- Tubeaxial
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polybutylene
- Power Rating
- 7W
- Terminal
- 2 Wire Leads
- Seri
- OD1238
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Lifetime Temp
- 65000 Hrs @ 45°C
- Montaj
- Flanges
- Rpm
- 2800 RPM
- RoHS Durumu
- ROHS3 Compliant
- Static Pressure
- 0.240 in H2O (59.8 Pa)
- Thickness
- 38.1mm
- Current Rating Amps
- 0.320A
- Yayın Yılı
- 2012
- Noise
- 43.0 dB
