Specifications
- Akım Değeri
- 500mA
- Kılıf / Paket
- Axial
- Fan Type
- Tubeaxial
- Life Hours
- 65000 hours
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Yükseklik
- 120mm
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Max Power Dissipation
- 6W
- Onay Kuruluşu
- cURus, TUV
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Bearing Type
- Ball
- Weight
- 329.999987g
- Nominal Gerilim
- 12VDC
- Fabrika Tedarik Süresi
- 19 Weeks
- Parça Durumu
- Active
- Noise
- 43.0 dB
- Static Pressure
- 0.240 in H2O (59.8 Pa)
- RoHS Durumu
- ROHS3 Compliant
- Rpm
- 2800 RPM
- Yayın Yılı
- 2009
- Current Rating Amps
- 0.5A
- Özellikler
- Locked Rotor Sensor
- Lifetime Temp
- 65000 Hrs @ 45°C
- Housing Material
- Plastic
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Seri
- OD1238
- Terminal
- 3 Wire Leads
- Power Rating
- 6W
