Specifications
- Parça Durumu
- Active
- Akım Değeri
- 170mA
- Power Consumption
- 4W
- Bearing Type
- Ball
- Housing Material
- Plastic
- Seri
- OD1225
- Nominal Gerilim
- 24VDC
- Operating Supply Voltage
- 24V
- Lifetime Temp
- 65000 Hrs @ 45°C
- Noise
- 38.0 dB
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yükseklik
- 120mm
- Power Rating
- 170mW
- Terminal
- 2 Wire Leads
- Kurşunsuz
- Lead Free
- Kılıf / Paket
- Axial
- Fan Type
- Tubeaxial
- RoHS Durumu
- ROHS3 Compliant
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Rpm
- 2050 RPM
- Current Rating Amps
- 0.170A
- Onay Kuruluşu
- cURus, TUV
- Yayın Yılı
- 2010
- Max Power Dissipation
- 4W
- Static Pressure
- 0.120 in H2O (29.9 Pa)
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Fabrika Tedarik Süresi
- 19 Weeks
- Depth
- 25mm
