Volume pricing
- 1+ pcs$15.26
- 10+ pcs$14.39
- 100+ pcs$13.58
- 500+ pcs$12.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Power Rating
- 200mW
- Yükseklik
- 120mm
- Kurşunsuz
- Lead Free
- Terminal
- 2 Wire Leads
- Kılıf / Paket
- Axial
- Fan Type
- Tubeaxial
- RoHS Durumu
- ROHS3 Compliant
- Material Blade
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Parça Durumu
- Active
- Power Consumption
- 3W
- Akım Değeri
- 240mA
- Bearing Type
- Ball
- Housing Material
- Plastic
- Seri
- OD1225
- Nominal Gerilim
- 12VDC
- Operating Supply Voltage
- 12V
- Noise
- 34.0 dB
- Lifetime Temp
- 65000 Hrs @ 45°C
- Material Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Yayın Yılı
- 2008
- Max Power Dissipation
- 3W
- Static Pressure
- 0.100 in H2O (24.9 Pa)
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Fabrika Tedarik Süresi
- 19 Weeks
- Depth
- 25mm
- Çalışma Sıcaklığı
- 14~158°F -10°C~70°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Rpm
- 1800 RPM
- Current Rating Amps
- 0.240A
- Onay Kuruluşu
- cURus, TUV
