Volume pricing
- 1+ pcs$16.16
- 10+ pcs$15.25
- 100+ pcs$14.38
- 500+ pcs$13.57
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- OA109
- Nominal Gerilim
- 115VAC
- Onay Kuruluşu
- cURus, TUV
- Yayın Yılı
- 2009
- Bearing Type
- Ball
- RoHS Durumu
- ROHS3 Compliant
- Voltage Range
- 80V~130VAC
- Material Blade
- Polybutylene Terephthalate (PBT)
- Güç (Watt)
- 12.00W
- Parça Durumu
- Active
- Boyut / Ölçü
- Square - 119.5mm Lx119.5mm H
- Static Pressure
- 0.160 in H2O (39.8 Pa)
- Özellikler
- Reverse Air Flow
- Fabrika Tedarik Süresi
- 15 Weeks
- Housing Material
- Aluminium
- Power Rating
- 12W
- Rpm
- 2300 RPM
- Fan Type
- Tubeaxial
- Kılıf / Paket
- Axial
- Noise
- 38.0 dB
- Material Frame
- Aluminum
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yükseklik
- 119.5mm
- Çalışma Sıcaklığı
- -4~176°F -20°C~80°C
- Terminal
- 2 Terminals
- Life Hours
- 60000 hours
- Thickness
- 38mm
- Max Power Dissipation
- 12W
- Lifetime Temp
- 60000 Hrs @ 40°C
