Specifications
- Montaj
- Through Hole
- Yükseklik
- 25.5mm
- Supply Voltagemax Vsup
- 5.25V
- Interface
- Parallel
- Terminal Sayısı
- 15
- Additional Feature
- ALSO OPERATES IN 10 TO 45 SUPPLY
- Power Dissipation
- 6.5W
- Logic Function
- AND
- Collector Emitter Voltage Vceo
- 45V
- Kılıf / Paket
- 15-SIP Formed Leads
- Power Supplies
- 524V
- HTS Kodu
- 8542.39.00.01
- Radyasyon Dayanımı
- No
- Kurşunsuz
- Lead Free
- Parça Durumu
- Obsolete
- Switchingfrequency
- 47kHz
- Besleme Gerilimi
- 4.75V~5.25V
- Yayın Yılı
- 2003
- Output Currentmax
- 2A
- JESD-609 Kodu
- e2
- Motor Type
- Stepper
- Nominal Supply Current
- 14mA
- Output Voltage
- 400mV
- Lifecycle Status
- OBSOLETE (Last Updated: 3 days ago)
- Output Configuration
- Half Bridge (2)
- Ambalaj
- Bulk
- Besleme Gerilimi
- 5V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Adımı
- 2mm
- Max Collector Current
- 1.7A
- Function
- Driver - Fully Integrated, Control and Power Stage
- Applications
- General Purpose
- Çalışma Sıcaklığı
- 150°C TJ
- Terminal Pozisyonu
- SINGLE
- Motor Type Stepper
- Unipolar
- Genişlik
- 8.5mm
- Terminal Kaplaması
- Tin/Nickel/Copper (Sn/Ni/Cu)
- Step Resolution
- 1, 1/2, 1/4, 1/8, 1/16
- Voltage Load
- 10V~45V
- Montaj Tipi
- Through Hole
