Specifications
- Output Current Per Channel
- 10A
- Fabrika Tedarik Süresi
- 4 Weeks
- Kılıf / Paket
- 23-SIP, 19 Leads, Formed Leads
- Collector Emitter Voltage Vceo
- 600V
- Besleme Gerilimi
- 12.5V~17.5V
- Switchingfrequency
- 20kHz
- Parça Durumu
- Not For New Designs
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Yayın Yılı
- 2003
- Lifecycle Status
- ACTIVE, NOT REC (Last Updated: 6 days ago)
- JESD-609 Kodu
- e2
- Output Configuration
- Half Bridge (3)
- Output Current
- 10A
- Yükseklik
- 21.8mm
- Montaj
- Through Hole
- Supply Voltagemax Vsup
- 450V
- Interface
- Logic
- Terminal Sayısı
- 19
- Number Of Outputs
- 3
- Özellikler
- Bootstrap Circuit
- Load Type
- Inductive
- Terminal Kaplaması
- Tin/Nickel (Sn/Ni)
- Fonksiyon Sayısı
- 1
- Analog Ic Other Type
- AC MOTOR CONTROLLER
- Voltage Load
- 450V Max
- Fault Protection
- Shoot-Through, UVLO
- Montaj Tipi
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 62mm
- Reach Svhc
- No SVHC
- Pin Sayısı
- 23
- Kurşunsuz Kodu
- yes
- Jesd30 Code
- R-XSFM-T19
- Ambalaj
- Tube
- Besleme Gerilimi
- 280V
- Max Output Current
- 20A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Collector Current
- 10A
- Applications
- AC Motors
