SS32

Specifications

Element Configuration

Single

Gross Weight

0.248g

Max Reverse Leakage Current

500μA

Voltage Forward Vf Max If

500mV @ 3A

Current Average Rectified Io

3A

Max Forward Impulse Current

70A

Forward Current

3A

Pin Sayısı

2

Maks. Çalışma Sıcaklığı

150°C

Montaj Tipi

Surface Mount

Peak Nonrepetitive Surge Current

100A

Parça Durumu

Active

Tedarikçi Cihaz Paketi

SMC (DO-214AB)

Max Repetitive Reverse Voltage Vrrm

20V

Peak Reverse Current

500μA

Weight

300mg

Terminal Sayısı

2

Nem Hassasiyeti (MSL)

1 (Unlimited)

Lifecycle Status

ACTIVE (Last Updated: 2 days ago)

Operating Temperature Junction

-55°C~150°C

Polarity

Standard

Case

SMC

Max Reverse Voltage Dc

20V

Max Forward Surge Current Ifsm

100A

Yayın Yılı

2013

RoHS Durumu

ROHS3 Compliant

Kurşunsuz

Lead Free

Ambalaj

Tape & Reel (TR)

Genişlik

6.25mm

Forward Voltage

500mV

Kılıf / Paket

DO-214AB, SMC

Mounting

SMD

Voltage Dc Reverse Vr Max

20V

Reach Svhc

No SVHC

Diode Type

Schottky

Number Of Elements

1

Average Rectified Current

3A

Temel Parça No

SS32

Current Reverse Leakage Vr

500μA @ 20V

Kind Of Package1

tape
