SS26FL

Specifications

Forward Current

2A

Diode Type

Schottky

Number Of Elements

1

Current Reverse Leakage Vr

40μA @ 60V

Maks. Çalışma Sıcaklığı

125°C

Average Rectified Current

2A

REACH Uyumluluk Kodu

not_compliant

Terminal Kaplaması

Tin (Sn)

Diode Element Material

SILICON

Montaj Tipi

Surface Mount

Seri

Automotive, AEC-Q101

Kılıf / Paket

SOD-123F

Reverse Currentmax

40μA

Element Configuration

Single

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Reverse Recovery Time

8.26 ns

HTS Kodu

8541.10.00.80

Terminal Pozisyonu

DUAL

Applications

GENERAL PURPOSE

JESD-609 Kodu

e3

Number Of Phases

1

Voltage Forward Vf Max If

700mV @ 2A

Operating Temperature Junction

-55°C~125°C

Lifecycle Status

ACTIVE (Last Updated: 1 day ago)

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Max Forward Surge Current Ifsm

50A

Max Reverse Voltage Dc

60V

Kurşunsuz Kodu

yes

ECCN Kodu

EAR99

Fabrika Tedarik Süresi

15 Weeks

Ambalaj

Tape & Reel (TR)

RoHS Durumu

ROHS3 Compliant

Parça Durumu

Active

Montaj

Surface Mount

Tepe Reflow Sıcaklığı (°C)

260

Jesd30 Code

R-PDSO-F2

Terminal Sayısı

2

Weight

27.6mg

Min. Çalışma Sıcaklığı

-55°C

Max Repetitive Reverse Voltage Vrrm

60V
