Specifications
- Parça Durumu
- Obsolete
- Ambalaj
- Tube
- Montaj Tipi
- Chassis Mount
- Collector Emitter Voltage Vceo
- 30 V
- Contact Plating
- Tin
- Wavelength
- 940 nm
- Sensing Method
- Through-Beam
- REACH Uyumluluk Kodu
- compliant
- Forward Current
- 50 mA
- Collectoremitter Breakdown Voltage
- 30 V
- Operating Supply Voltage
- 1.7 V
- RoHS
- Compliant
- Pin Sayısı
- 4
- Çalışma Sıcaklığı
- -40°C~85°C
- Rise Time
- 8 µs
- Yayın Yılı
- 2013
- Power Dissipation
- 100 mW
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Reverse Breakdown Voltage
- 5 V
- Maks. Çalışma Sıcaklığı
- 85 °C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Output Configuration
- Phototransistor
- Montaj
- Screw
- Response Time
- 8μs, 50μs
- Voltage Collector Emitter Breakdown Max
- 30V
- Kılıf / Paket
- Module, Pre-Wired
- Weight
- 2.448 g
- Current Dc Forward If Max
- 50mA
- Number Of Elements
- 1
- Min. Çalışma Sıcaklığı
- -40 °C
- Tip
- Unamplified
- Algılama Mesafesi
- 0.095 (2.41mm)
