Specifications
- Prop Delaynomsup
- 22 ns
- Maks. Oturma Yüksekliği
- 2.65mm
- Genişlik
- 7.5mm
- Power Dissipation Max
- 500mW
- Propagation Delay
- 75 ns
- Tepe Reflow Sıcaklığı (°C)
- 240
- Number Of Ports
- 2
- Number Of Circuits
- 8
- Terminal Pozisyonu
- DUAL
- Terminal Kaplaması
- Tin/Lead (Sn/Pb)
- Polarity
- Non-Inverting
- Montaj
- Surface Mount
- Terminal Formu
- GULL WING
- Control Type
- COMMON CONTROL
- Logic Function
- Inverting, Transceiver
- Count Direction
- BIDIRECTIONAL
- Min. Çalışma Sıcaklığı
- -55°C
- Jesd30 Code
- R-PDSO-G20
- High Level Output Current
- 7.8mA
- Max Iol
- 0.006 A
- Besleme Gerilimi
- 3V
- Family
- HC/UH
- Kurşunsuz
- Contains Lead
- Pin Sayısı
- 20
- Fonksiyon Sayısı
- 1
- Maks. Çalışma Sıcaklığı
- 125°C
- Logic Ic Type
- BUS TRANSCEIVER
- Yayın Yılı
- 2005
- Output Characteristics
- 3-STATE
- Packing Method
- TAPE AND REEL
- Qualification Status
- Not Qualified
- Tepe Reflow Süresi (maks. sn)
- 30
- Ambalaj
- Cut Tape (CT)
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Number Of Bits
- 8
- Terminal Sayısı
- 20
- JESD-609 Kodu
- e0
- Translation
- N/A
- Temperature Grade
- MILITARY
- Min Supply Voltage
- 2V
