Specifications
- Power Dissipation Max
- 500mW
- JESD-609 Kodu
- e0
- Logic Ic Type
- BUS TRANSCEIVER
- Additional Feature
- WITH COMMON OUTPUT ENABLE AND DIRECTION CONTROL
- Count Direction
- BIDIRECTIONAL
- Number Of Bits
- 8
- Maks. Oturma Yüksekliği
- 2.65mm
- Terminal Sayısı
- 20
- Min. Çalışma Sıcaklığı
- -40°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Propagation Delay
- 8.5 ns
- Max Supply Voltage
- 6V
- Ambalaj
- Cut Tape (CT)
- Number Of Ports
- 2
- Number Of Circuits
- 8
- Family
- AC
- Kurşunsuz
- Contains Lead
- Logic Function
- Inverting, Transceiver
- Terminal Formu
- GULL WING
- Output Characteristics
- 3-STATE
- Tepe Reflow Süresi (maks. sn)
- 30
- Genişlik
- 7.5mm
- Terminal Pozisyonu
- DUAL
- Maks. Çalışma Sıcaklığı
- 85°C
- Power Supplies
- 3.3/5V
- Max Iol
- 0.024 A
- Polarity
- Non-Inverting
- Prop Delaynomsup
- 9 ns
- Pin Sayısı
- 20
- High Level Output Current
- 24mA
- Number Of Elements
- 1
- Yayın Yılı
- 2006
- Fonksiyon Sayısı
- 1
- Pin Sayısı
- 20
- Min Supply Voltage
- 2V
- Control Type
- COMMON CONTROL
- RoHS Durumu
- RoHS Compliant
- Besleme Gerilimi
- 5V
- Temperature Grade
- INDUSTRIAL
- Terminal Kaplaması
- Tin/Lead (Sn/Pb)
