Specifications
- Bandwidth
- 20 kHz
- Power Dissipation
- 50W
- Çalışma Sıcaklığı
- -40°C~85°C TA
- Yayın Yılı
- 2011
- Nominal Supply Current
- 400mA
- Output Power
- 28W
- ECCN Kodu
- EAR99
- Terminal Pozisyonu
- ZIG-ZAG
- Jesd30 Code
- R-XZFM-T25
- Özellikler
- Mute, Short-Circuit and Thermal Protection, Standby
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz Kodu
- yes
- Çıkış Tipi
- 4-Channel (Quad)
- Supply Voltagemin Vsup
- 9V
- Voltage Gain
- 26dB
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pin Sayısı
- 36
- Common Mode Rejection Ratio
- 65 dB
- Max Output Current
- 18mA
- Gain
- 26 dB
- Max Output Power X Channels Load
- 48W x 4 @ 4 Ω
- Number Of Channels
- 4
- Operating Supply Voltage
- 14.4V
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 3 days ago)
- Radyasyon Dayanımı
- No
- Harmonic Distortion
- 0.03%
- Max Output Power
- 48W
- Fonksiyon Sayısı
- 1
- Terminal Kaplaması
- Tin/Bismuth (Sn/Bi)
- Pin Sayısı
- 36
- Yüzey Montaj
- NO
- Tip
- Class AB
- Terminal Adımı
- 1mm
- Besleme Gerilimi
- 9V~16V
- Temel Parça No
- LV47017
- Terminal Sayısı
- 25
- Kılıf / Paket
- 25-SSIP Exposed Pad, Formed Leads
- Ambalaj
- Tube
- Max Power Dissipation
- 50W
- Supply Voltagemax Vsup
- 16V
