Volume pricing
- 1+ pcs$6.41
- 10+ pcs$6.05
- 100+ pcs$5.71
- 500+ pcs$5.38
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Peak Nonrepetitive Surge Current
- 300A
- Current Reverse Leakage Vr
- 5μA @ 1000V
- Kılıf / Paket
- 4-Square, GBPC-W
- Kurşunsuz
- Lead Free
- Akım Değeri
- 12A
- Fabrika Tedarik Süresi
- 12 Weeks
- Max Forward Surge Current Ifsm
- 300A
- Power Dissipation
- 83.3W
- Radyasyon Dayanımı
- No
- Montaj
- Through Hole
- ECCN Kodu
- EAR99
- Yükseklik
- 11.23mm
- Max Surge Current
- 300A
- Kapasitans
- 180pF
- Weight
- 17.21g
- Pin Sayısı
- 4
- Additional Feature
- UL RECOGNIZED
- RoHS Durumu
- ROHS3 Compliant
- Diode Type
- Single Phase
- Uzunluk
- 29mm
- Montaj Tipi
- Through Hole
- Max Reverse Leakage Current
- 5μA
- Output Current
- 12A
- Genişlik
- 29mm
- Peak Reverse Current
- 5μA
- Voltage Rated Dc
- 1kV
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Lifecycle Status
- ACTIVE (Last Updated: 1 week ago)
- Temel Parça No
- GBPC1210
- Forward Voltage
- 1.1V
- Diode Element Material
- SILICON
- Max Repetitive Reverse Voltage Vrrm
- 1kV
- Terminal Pozisyonu
- UPPER
- Number Of Phases
- 1
- Case Connection
- ISOLATED
- Terminal Formu
- WIRE
- Terminal Sayısı
- 4
- Element Configuration
- Single
- Number Of Elements
- 1
