Volume pricing
- 1+ pcs$15.73
- 10+ pcs$14.84
- 100+ pcs$14.00
- 500+ pcs$13.21
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Weight
- 21.978g
- RoHS Durumu
- RoHS Compliant
- Montaj
- Through Hole
- HTS Kodu
- 8541.29.00.95
- Radyasyon Dayanımı
- No
- Kurşunsuz
- Lead Free
- Voltage Isolation
- 2500Vrms
- Terminal Sayısı
- 27
- Nominal Supply Current
- 23mA
- Temperature Grade
- AUTOMOTIVE
- Usage Level
- Automotive grade
- Turn On Delay Time
- 750 ns
- Seri
- Motion SPM® 3
- Turn Off Delay Time
- 600 ns
- Kılıf / Paket
- 27-PowerDIP Module (1.205, 30.60mm)
- Fonksiyon Sayısı
- 1
- Output Current
- 10A
- Pin Sayısı
- 27
- Besleme Gerilimi
- 15V
- Min. Çalışma Sıcaklığı
- -40°C
- Configuration
- 3 Phase
- Frekans
- 20kHz
- Supply Voltagemin Vsup
- 13.5V
- Tip
- IGBT
- Operating Supply Voltage
- 300V
- Maks. Çalışma Sıcaklığı
- 150°C
- JESD-609 Kodu
- e3
- Terminal Pozisyonu
- DUAL
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 2 days ago)
- Parça Durumu
- Obsolete
- Terminal Kaplaması
- Tin (Sn)
- Max Current Rating
- 5A
- Max Collector Current
- 5A
- ECCN Kodu
- EAR99
- Uzunluk
- 44mm
- Power Dissipation
- 19W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yükseklik
- 5.5mm
- Kurşunsuz Kodu
- yes
- Genişlik
- 26.8mm
