Specifications
- Genişlik
- 27mm
- Yükseklik
- 5.3mm
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Power Dissipation
- 20W
- Min Breakdown Voltage
- 600V
- Collector Emitter Voltage Vceo
- 2.2V
- Output Voltage
- 400V
- Yayın Yılı
- 2014
- Montaj Tipi
- Through Hole
- Parça Durumu
- Obsolete
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 2 days ago)
- Terminal Pozisyonu
- DUAL
- JESD-609 Kodu
- e3
- Maks. Çalışma Sıcaklığı
- 150°C
- Tip
- IGBT
- Operating Supply Voltage
- 20V
- Uzunluk
- 44mm
- ECCN Kodu
- EAR99
- Max Collector Current
- 10A
- Max Current Rating
- 10A
- Terminal Kaplaması
- Tin (Sn)
- Fonksiyon Sayısı
- 4
- Kılıf / Paket
- 27-PowerDIP Module (1.205, 30.60mm)
- Number Of Outputs
- 3
- Seri
- Motion SPM® 3
- Configuration
- 3 Phase
- Min. Çalışma Sıcaklığı
- -40°C
- Besleme Gerilimi
- 15V
- Max Supply Voltage
- 450V
- Output Current
- 10A
- Pin Sayısı
- 27
- HTS Kodu
- 8541.29.00.95
- Montaj
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Weight
- 21.001333g
- Temperature Grade
- AUTOMOTIVE
- Nominal Supply Current
- 600μA
- Terminal Sayısı
- 27
- Voltage Isolation
- 2500Vrms
