Specifications
- Terminal Sayısı
- 27
- Nominal Supply Current
- 600μA
- Temperature Grade
- AUTOMOTIVE
- Voltage Isolation
- 2500Vrms
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Weight
- 21.978g
- RoHS Durumu
- RoHS Compliant
- Montaj
- Through Hole
- HTS Kodu
- 8541.29.00.95
- Min. Çalışma Sıcaklığı
- -40°C
- Besleme Gerilimi
- 15V
- Max Supply Voltage
- 450V
- Pin Sayısı
- 27
- Output Current
- 20A
- Frekans
- 20kHz
- Configuration
- 3 Phase
- Number Of Outputs
- 3
- Seri
- Motion SPM® 3
- Turn On Delay Time
- 750 ns
- Fonksiyon Sayısı
- 1
- Kılıf / Paket
- 27-PowerDIP Module (1.205, 30.60mm)
- Turn Off Delay Time
- 600 ns
- Max Collector Current
- 10A
- ECCN Kodu
- EAR99
- Max Current Rating
- 10A
- Terminal Kaplaması
- Tin (Sn)
- Uzunluk
- 44mm
- Maks. Çalışma Sıcaklığı
- 150°C
- Tip
- IGBT
- Operating Supply Voltage
- 20V
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 2 days ago)
- Parça Durumu
- Obsolete
- JESD-609 Kodu
- e3
- Terminal Pozisyonu
- DUAL
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 2008
- Min Breakdown Voltage
- 600V
- Collector Emitter Voltage Vceo
- 2.2V
- Output Voltage
- 400V
