Volume pricing
- 1+ pcs$72.51
- 10+ pcs$68.40
- 100+ pcs$64.53
- 500+ pcs$60.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pin Sayısı
- 27
- Output Current
- 10A
- Min. Çalışma Sıcaklığı
- -40°C
- Max Supply Voltage
- 900V
- Besleme Gerilimi
- 15V
- Fabrika Tedarik Süresi
- 6 Weeks
- Frekans
- 20kHz
- Configuration
- 3 Phase
- Seri
- Motion SPM® 3
- Number Of Outputs
- 3
- Kılıf / Paket
- 27-PowerDIP Module (1.205, 30.60mm)
- Fonksiyon Sayısı
- 1
- Radyasyon Dayanımı
- No
- Terminal Sayısı
- 27
- Temperature Grade
- AUTOMOTIVE
- Voltage Isolation
- 2500Vrms
- Power Supplies
- 15V
- RoHS Durumu
- ROHS3 Compliant
- Weight
- 13.32g
- Montaj
- Through Hole
- HTS Kodu
- 8541.29.00.95
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 2014
- Max Power Dissipation
- 69W
- Collector Emitter Voltage Vceo
- 2.8V
- Output Voltage
- 1.2kV
- Min Breakdown Voltage
- 1.2kV
- Yükseklik
- 5.7mm
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Genişlik
- 27mm
- Max Current Rating
- 10A
- Max Collector Current
- 10A
- ECCN Kodu
- EAR99
- Uzunluk
- 44.2mm
- Tip
- IGBT
- Operating Supply Current
- 5mA
- Operating Supply Voltage
- 600V
- Maks. Çalışma Sıcaklığı
- 150°C
- Terminal Pozisyonu
- DUAL
