Volume pricing
- 1+ pcs$2.74
- 10+ pcs$2.59
- 100+ pcs$2.44
- 500+ pcs$2.30
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Power Supplies
- 15V
- Voltage Isolation
- 1500Vrms
- Terminal Sayısı
- 27
- Montaj
- Surface Mount
- HTS Kodu
- 8541.29.00.95
- Weight
- 2.174663g
- RoHS Durumu
- RoHS Compliant
- Configuration
- 3 Phase
- Frekans
- 15kHz
- Pin Sayısı
- 27
- Fabrika Tedarik Süresi
- 31 Weeks
- Qualification Status
- Not Qualified
- Besleme Gerilimi
- 15V
- Max Supply Voltage
- 200V
- Min. Çalışma Sıcaklığı
- -40°C
- Ambalaj
- Tape & Reel (TR)
- Kılıf / Paket
- 27-PowerLQFN Module
- Fonksiyon Sayısı
- 1
- Terminal Formu
- NO LEAD
- Seri
- Motion SPM® 7
- Number Of Outputs
- 3
- Uzunluk
- 13mm
- Terminal Kaplaması
- Tin (Sn)
- Max Current Rating
- 6.9A
- Max Collector Current
- 6.9A
- ECCN Kodu
- EAR99
- JESD-609 Kodu
- e3
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Terminal Pozisyonu
- QUAD
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 1 day ago)
- Parça Durumu
- Obsolete
- Tip
- MOSFET
- Operating Supply Current
- 1.7mA
- Operating Supply Voltage
- 150V
- Maks. Çalışma Sıcaklığı
- 150°C
- Tepe Reflow Sıcaklığı (°C)
- 260
- Collector Emitter Voltage Vceo
- 250V
- Min Breakdown Voltage
- 250V
- Max Power Dissipation
- 81W
- Switchingfrequency
- 15kHz
