Specifications
- Output Current
- 110A
- Min Breakdown Voltage
- 600V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Power Dissipation
- 189W
- Yayın Yılı
- 2011
- Collectoremitter Saturation Voltage
- 2.4V
- JESD-609 Kodu
- e3
- Pin Sayısı
- 32
- Supply Voltagemin Vsup
- 13.5V
- Uzunluk
- 60mm
- Terminal Sayısı
- 32
- Lifecycle Status
- ACTIVE, NOT REC (Last Updated: 4 days ago)
- Max Current Rating
- 75A
- HTS Kodu
- 8541.29.00.95
- Configuration
- 3 Phase
- Maks. Çalışma Sıcaklığı
- 125°C
- Collector Emitter Voltage Vceo
- 2.4V
- Collectoremitter Breakdown Voltage
- 600V
- ECCN Kodu
- EAR99
- Weight
- 46.938g
- Radyasyon Dayanımı
- No
- Fabrika Tedarik Süresi
- 6 Weeks
- Supply Voltagemax Vsup
- 16.5V
- Frekans
- 5kHz
- Terminal Kaplaması
- TIN
- Kılıf / Paket
- 32-PowerDIP Module (1.370, 34.80mm)
- Tip
- IGBT
- Nominal Input Voltage
- 253V
- Voltage Isolation
- 2500Vrms
- Seri
- Motion SPM® 2
- Tepe Reflow Sıcaklığı (°C)
- 260
- Min. Çalışma Sıcaklığı
- -20°C
- Yükseklik
- 7.2mm
- Max Power Dissipation
- 189W
- Montaj
- Through Hole
- Fonksiyon Sayısı
- 1
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Through Hole
- Parça Durumu
- Not For New Designs
