Specifications
- Yükseklik
- 7.2mm
- Montaj
- Through Hole
- Fonksiyon Sayısı
- 1
- Polarity
- NPN
- Min. Çalışma Sıcaklığı
- -20°C
- Seri
- Motion SPM® 2
- Nominal Input Voltage
- 253V
- Tip
- IGBT
- Voltage Isolation
- 2500Vrms
- RoHS Durumu
- RoHS Compliant
- Reach Svhc
- No SVHC
- Parça Durumu
- Obsolete
- Terminal Pozisyonu
- DUAL
- Besleme Gerilimi
- 15V
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Through Hole
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 1 week ago)
- Uzunluk
- 60mm
- Terminal Sayısı
- 32
- Pin Sayısı
- 32
- Supply Voltagemin Vsup
- 13.5V
- Collectoremitter Saturation Voltage
- 2.5V
- Power Dissipation
- 43W
- Yayın Yılı
- 2011
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Output Current
- 20A
- Min Breakdown Voltage
- 600V
- Genişlik
- 31mm
- Kurşunsuz Kodu
- yes
- Rise Time
- 270ns
- Terminal Kaplaması
- Tin (Sn)
- Kılıf / Paket
- 32-PowerDIP Module (1.370, 34.80mm)
- Frekans
- 15kHz
- Radyasyon Dayanımı
- No
- Weight
- 32.58g
- Collectoremitter Breakdown Voltage
- 600V
- Collector Emitter Voltage Vceo
- 2.5V
- Maks. Çalışma Sıcaklığı
- 125°C
- Max Current Rating
- 10A
