Specifications
- Collector Emitter Voltage Vceo
- 2.1V
- Besleme Gerilimi
- 15V
- Akım
- 40A
- Pin Sayısı
- 27
- HTS Kodu
- 8541.29.00.95
- Voltage Isolation
- 2500Vrms
- Kılıf / Paket
- 27-PowerDIP Module (1.205, 30.60mm)
- Montaj
- Through Hole
- Power Supplies
- 15V
- Qualification Status
- Not Qualified
- Fonksiyon Sayısı
- 1
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Supply Voltagemax Vsup
- 16.5V
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Seri
- PFC SPM® 3
- Min. Çalışma Sıcaklığı
- -40°C
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Parça Durumu
- Active
- Max Collector Current
- 40A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Weight
- 21.978g
- JESD-609 Kodu
- e3
- Max Breakdown Voltage
- 600V
- Max Power Dissipation
- 2W
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 8 Weeks
- Genişlik
- 26.8mm
- Configuration
- 2 Phase
- Yayın Yılı
- 2006
- Terminal Sayısı
- 27
- Maks. Çalışma Sıcaklığı
- 150°C
- Terminal Pozisyonu
- DUAL
- Uzunluk
- 44mm
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Yükseklik
- 5.5mm
- Supply Voltagemin Vsup
- 13.5V
- Tip
- IGBT
- RoHS Durumu
- ROHS3 Compliant
- Switchingfrequency
- 20kHz
