Specifications
- Input Current
- 20mA
- ECCN Kodu
- EAR99
- Max Input Current
- 30mA
- Currentholdih
- 500μA
- Zerocrossing Circuit
- No
- Rise Time
- 60μs
- Max Input Voltage
- 1.5V
- Nominal Input Voltage
- 1.28V
- Yükseklik
- 4mm
- Montaj Tipi
- Through Hole
- Configuration
- SINGLE
- Max Power Dissipation
- 500mW
- Pin Sayısı
- 6
- Input Trigger Currentnom
- 0.75mA
- Additional Feature
- UL RECOGNIZED
- Rms Current Irms
- 300mA
- Onstate Voltagemax
- 3V
- Kılıf / Paket
- 6-DIP (0.300, 7.62mm)
- RoHS Durumu
- ROHS3 Compliant
- Reverse Breakdown Voltage
- 6V
- Number Of Elements
- 1
- Hold Current
- 500μA
- Static Dvdt Min
- 10kV/μs
- Yayın Yılı
- 2009
- Ambalaj
- Tube
- Forward Current
- 30mA
- Kurşunsuz
- Lead Free
- Çalışma Sıcaklığı
- -55°C~100°C
- Parça Durumu
- Active
- Turn On Delay Time
- 60 μs
- Number Of Channels
- 1
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 7 Weeks
- Montaj
- Through Hole
- Kurşunsuz Kodu
- yes
- Onstate Currentmax
- 0.3A
- Terminal Kaplaması
- Tin (Sn)
- Genişlik
- 7mm
- Uzunluk
- 7.8mm
- Onay Kuruluşu
- cUL, FIMKO, UL
