Specifications
- Lifecycle Status
- ACTIVE (Last Updated: 19 hours ago)
- Çıkış Tipi
- Triac
- Power Dissipation
- 500mW
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Repetitive Peak Offstate Voltage
- 800V
- Weight
- 0g
- JESD-609 Kodu
- e3
- Currentled Triggeriftmax
- 2mA
- Voltageoff State
- 800V
- Output Current
- 300mA
- Voltage Isolation
- 5000Vrms
- Peak Surge Current
- 3A
- Max Output Current
- 300mA
- Onay Kuruluşu
- CSA, UL, VDE
- Terminal Kaplaması
- Tin (Sn)
- Montaj
- Surface Mount
- Onstate Currentmax
- 0.07A
- Kurşunsuz Kodu
- yes
- Fabrika Tedarik Süresi
- 9 Weeks
- Reach Svhc
- No SVHC
- Number Of Channels
- 1
- Turn On Delay Time
- 60 μs
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~100°C
- Forward Current
- 30mA
- Ambalaj
- Tape & Reel (TR)
- Yayın Yılı
- 2009
- Static Dvdt Min
- 10kV/μs
- Hold Current
- 500μA
- Number Of Elements
- 1
- Reverse Breakdown Voltage
- 6V
- RoHS Durumu
- ROHS3 Compliant
- Kılıf / Paket
- 6-SMD, Gull Wing
- Rms Current Irms
- 300mA
- Onstate Voltagemax
- 3V
- Additional Feature
- UL RECOGNIZED, VDE APPROVED
- Output Current Per Channel
- 300mA
- Input Trigger Currentnom
- 0.65mA
- Pin Sayısı
- 6
- Montaj Tipi
- Surface Mount
