Specifications
- Parça Durumu
- Not For New Designs
- Min. Çalışma Sıcaklığı
- -40°C
- Terminal Sayısı
- 26
- Collector Emitter Voltage Vceo
- 2V
- Lifecycle Status
- ACTIVE, NOT REC (Last Updated: 1 week ago)
- Max Power Dissipation
- 34W
- Analog Ic Other Type
- AC MOTOR CONTROLLER
- JESD-609 Kodu
- e3
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Montaj Tipi
- Through Hole
- Additional Feature
- CONTROL SUPPLY VOLTAGE(VCC)= 15V
- Terminal Pozisyonu
- DUAL
- Weight
- 16.712g
- Supply Voltagemax Vsup
- 400V
- REACH Uyumluluk Kodu
- not_compliant
- Seri
- Motion-SPM®
- Output Currentmax
- 15A
- Max Current Rating
- 10A
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Collectoremitter Saturation Voltage
- 1.7V
- Fabrika Tedarik Süresi
- 45 Weeks
- Min Breakdown Voltage
- 600V
- Kurşunsuz Kodu
- yes
- Maks. Çalışma Sıcaklığı
- 150°C
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Fonksiyon Sayısı
- 1
- Yayın Yılı
- 2016
- Jesd30 Code
- R-XDFM-T26
- Terminal Kaplaması
- Tin (Sn)
- Montaj
- Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Besleme Gerilimi
- 300V
