Specifications
- Max Supply Voltage
- 400V
- Weight
- 17.088g
- Terminal Pozisyonu
- DUAL
- HTS Kodu
- 8541.29.00.95
- Genişlik
- 23.5mm
- Montaj Tipi
- Through Hole
- JESD-609 Kodu
- e3
- Tip
- IGBT
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Operating Supply Voltage
- 15V
- Collector Emitter Voltage Vceo
- 2.35V
- Pin Sayısı
- 26
- Radyasyon Dayanımı
- No
- Terminal Sayısı
- 26
- Min. Çalışma Sıcaklığı
- -40°C
- Max Collector Current
- 20A
- Parça Durumu
- Active
- Power Dissipation
- 50W
- Configuration
- 3 Phase
- Besleme Gerilimi
- 15V
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Through Hole
- Terminal Kaplaması
- Tin (Sn)
- Yayın Yılı
- 2014
- Min Supply Voltage
- 13.5V
- Fonksiyon Sayısı
- 1
- Uzunluk
- 39.5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switchingfrequency
- 5kHz
- Maks. Çalışma Sıcaklığı
- 150°C
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Min Breakdown Voltage
- 600V
- Fabrika Tedarik Süresi
- 8 Weeks
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Max Current Rating
- 20A
- Supply Currentmax Isup
- 4mA
- Voltage Isolation
- 2000Vrms
- Seri
- Motion SPM® 45
- Yükseklik
- 4.8mm
