Volume pricing
- 1+ pcs$9.43
- 10+ pcs$8.90
- 100+ pcs$8.39
- 500+ pcs$7.92
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Collector Emitter Voltage Vceo
- 2.2V
- Operating Supply Voltage
- 300V
- Terminal Sayısı
- 20
- Number Of Outputs
- 3
- Min. Çalışma Sıcaklığı
- -40°C
- Parça Durumu
- Obsolete
- Supply Voltagemin Vsup
- 14V
- Output Voltage
- 600V
- Supply Voltagemax Vsup
- 16.5V
- Weight
- 5.70216g
- Terminal Pozisyonu
- DUAL
- HTS Kodu
- 8541.29.00.95
- Genişlik
- 21mm
- Montaj Tipi
- Through Hole
- Qualification Status
- Not Qualified
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Lifecycle Status
- LAST SHIPMENTS (Last Updated: 2 days ago)
- Max Power Dissipation
- 22W
- Tip
- IGBT
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Power Supplies
- 15V
- Maks. Çalışma Sıcaklığı
- 150°C
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Min Breakdown Voltage
- 600V
- Fabrika Tedarik Süresi
- 6 Weeks
- Max Current Rating
- 15A
- Kılıf / Paket
- 20-PowerDIP Module (1.220, 31.00mm)
- Frekans
- 20kHz
- Supply Currentmax Isup
- 4mA
- Operating Supply Current
- 2.7mA
- Voltage Isolation
- 1500Vrms
- Seri
- Motion SPM® 55
- Output Current
- 15A
- Configuration
- 3 Phase Inverter
- Besleme Gerilimi
- 15V
- RoHS Durumu
- RoHS Compliant
- Maks. Oturma Yüksekliği
- 6mm
- Montaj
- Through Hole
