Specifications
- Yükseklik
- 6.5mm
- Output Current
- 15A
- Voltage Isolation
- 2000Vrms
- Seri
- Motion SPM® 45
- Collectoremitter Saturation Voltage
- 1.6V
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Max Current Rating
- 15A
- Fabrika Tedarik Süresi
- 45 Weeks
- ECCN Kodu
- EAR99
- Min Breakdown Voltage
- 600V
- Kurşunsuz Kodu
- yes
- Power Supplies
- 15V
- Maks. Çalışma Sıcaklığı
- 150°C
- Switchingfrequency
- 20kHz
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 39mm
- Min Supply Voltage
- 13.5V
- Fonksiyon Sayısı
- 1
- Terminal Kaplaması
- Tin (Sn)
- Montaj
- Through Hole
- Yayın Yılı
- 2014
- RoHS Durumu
- ROHS3 Compliant
- Besleme Gerilimi
- 15V
- Configuration
- 3 Phase
- Max Collector Current
- 15A
- Min. Çalışma Sıcaklığı
- -40°C
- Parça Durumu
- Not For New Designs
- Max Junction Temperature Tj
- 150°C
- Number Of Outputs
- 3
- Terminal Sayısı
- 26
- Radyasyon Dayanımı
- No
- Pin Sayısı
- 26
- Collector Emitter Voltage Vceo
- 2.1V
- Max Power Dissipation
- 34W
- Tip
- IGBT
- Lifecycle Status
- ACTIVE, NOT REC (Last Updated: 2 days ago)
- JESD-609 Kodu
- e3
- Genişlik
- 23mm
- Montaj Tipi
- Through Hole
- Terminal Pozisyonu
- DUAL
