Volume pricing
- 1+ pcs$11.95
- 10+ pcs$11.28
- 100+ pcs$10.64
- 500+ pcs$10.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pin Sayısı
- 26
- Collector Emitter Voltage Vceo
- 1.9V
- Terminal Sayısı
- 26
- Radyasyon Dayanımı
- No
- Parça Durumu
- Active
- Min. Çalışma Sıcaklığı
- -40°C
- Max Collector Current
- 5A
- Kurşunsuz
- Lead Free
- Weight
- 16.712g
- Max Supply Voltage
- 16.5V
- HTS Kodu
- 8541.29.00.95
- Terminal Pozisyonu
- DUAL
- Montaj Tipi
- Through Hole
- Genişlik
- 23.5mm
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Max Power Dissipation
- 29W
- Tip
- IGBT
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 39.5mm
- Kurşunsuz Kodu
- yes
- Min Breakdown Voltage
- 600V
- ECCN Kodu
- EAR99
- Maks. Çalışma Sıcaklığı
- 150°C
- Switchingfrequency
- 20kHz
- Power Supplies
- 15V
- Supply Currentmax Isup
- 3.65mA
- Threshold Voltage
- 2.6V
- Frekans
- 20kHz
- Collectoremitter Saturation Voltage
- 1.4V
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Max Current Rating
- 5A
- Fabrika Tedarik Süresi
- 8 Weeks
- Yükseklik
- 4.5mm
- Seri
- Motion SPM® 45
- Voltage Isolation
- 2000Vrms
- Configuration
- 3 Phase
- Besleme Gerilimi
- 15V
- Yayın Yılı
- 2014
- Montaj
- Through Hole
