Specifications
- Montaj Tipi
- Through Hole
- Temperature Grade
- AUTOMOTIVE
- Tip
- IGBT
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- JESD-609 Kodu
- e3
- Weight
- 21.978g
- Supply Voltagemax Vsup
- 16.5V
- Terminal Pozisyonu
- DUAL
- Parça Durumu
- Active
- Min. Çalışma Sıcaklığı
- -40°C
- Supply Voltagemin Vsup
- 14V
- Collector Emitter Voltage Vceo
- 2.25V
- Terminal Sayısı
- 27
- Yayın Yılı
- 2017
- Jesd30 Code
- R-XDFM-T27
- Terminal Kaplaması
- Tin (Sn)
- Montaj
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Fonksiyon Sayısı
- 1
- Configuration
- 3 Phase Inverter
- Besleme Gerilimi
- 15V
- Kılıf / Paket
- 27-PowerDIP Module (1.205, 30.60mm)
- Max Current Rating
- 50A
- Fabrika Tedarik Süresi
- 8 Weeks
- Seri
- Motion SPM® 3
- Output Currentmax
- 100A
- Voltage Isolation
- 2500Vrms
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Kurşunsuz Kodu
- yes
- Min Breakdown Voltage
- 600V
- Maks. Çalışma Sıcaklığı
- 150°C
