Specifications
- Pin Sayısı
- 26
- Collector Emitter Voltage Vceo
- 2.3V
- Terminal Adımı
- 2.54mm
- Terminal Sayısı
- 26
- Parça Durumu
- Not For New Designs
- Min. Çalışma Sıcaklığı
- -40°C
- Max Collector Current
- 15A
- Kurşunsuz
- Lead Free
- Weight
- 17.088g
- Max Supply Voltage
- 16.5V
- HTS Kodu
- 8541.29.00.95
- Terminal Pozisyonu
- DUAL
- Montaj Tipi
- Through Hole
- Genişlik
- 23.5mm
- Lifecycle Status
- ACTIVE, NOT REC (Last Updated: 2 days ago)
- Max Power Dissipation
- 41W
- Tip
- IGBT
- Qualification Status
- Not Qualified
- JESD-609 Kodu
- e3
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 39.5mm
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Kurşunsuz Kodu
- yes
- Min Breakdown Voltage
- 600V
- ECCN Kodu
- EAR99
- Switchingfrequency
- 5kHz
- Maks. Çalışma Sıcaklığı
- 150°C
- Power Supplies
- 15V
- Supply Currentmax Isup
- 3.65mA
- Max Current Rating
- 15A
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Collectoremitter Saturation Voltage
- 1.8V
- Fabrika Tedarik Süresi
- 46 Weeks
- REACH Uyumluluk Kodu
- not_compliant
- Yükseklik
- 4.8mm
- Output Currentmax
- 30A
- Seri
- Motion SPM® 45
- Voltage Isolation
- 2000Vrms
- Configuration
- 3 Phase
