Specifications
- Yayın Yılı
- 2014
- Montaj
- Through Hole
- Terminal Kaplaması
- Tin (Sn)
- RoHS Durumu
- ROHS3 Compliant
- Min Supply Voltage
- 13.5V
- Fonksiyon Sayısı
- 1
- Configuration
- 3 Phase
- Besleme Gerilimi
- 15V
- Supply Currentmax Isup
- 3.65mA
- Collectoremitter Saturation Voltage
- 1.7V
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Max Current Rating
- 10A
- Fabrika Tedarik Süresi
- 8 Weeks
- REACH Uyumluluk Kodu
- not_compliant
- Yükseklik
- 4.5mm
- Output Currentmax
- 20A
- Seri
- Motion SPM® 45
- Voltage Isolation
- 2000Vrms
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 39.5mm
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Min Breakdown Voltage
- 600V
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Maks. Çalışma Sıcaklığı
- 150°C
- Switchingfrequency
- 5kHz
- Power Supplies
- 15V
- Montaj Tipi
- Through Hole
- Genişlik
- 23.5mm
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Max Power Dissipation
- 34W
- Tip
- IGBT
- Qualification Status
- Not Qualified
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- JESD-609 Kodu
- e3
- Max Supply Voltage
- 16.5V
- Weight
- 17.088g
- HTS Kodu
- 8541.29.00.95
- Terminal Pozisyonu
- DUAL
- Parça Durumu
- Active
