Volume pricing
- 1+ pcs$17.78
- 10+ pcs$16.78
- 100+ pcs$15.83
- 500+ pcs$14.93
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Besleme Gerilimi
- 15V
- Configuration
- 3 Phase
- Min Supply Voltage
- 13.5V
- Fonksiyon Sayısı
- 1
- RoHS Durumu
- ROHS3 Compliant
- Montaj
- Through Hole
- Terminal Kaplaması
- Tin (Sn)
- Yayın Yılı
- 2014
- Power Supplies
- 15V
- Maks. Çalışma Sıcaklığı
- 150°C
- Switchingfrequency
- 5kHz
- ECCN Kodu
- EAR99
- Min Breakdown Voltage
- 600V
- Kurşunsuz Kodu
- yes
- Uzunluk
- 39.5mm
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Isolation
- 2000Vrms
- Output Currentmax
- 20A
- Seri
- Motion SPM® 45
- Yükseklik
- 4.5mm
- REACH Uyumluluk Kodu
- not_compliant
- Fabrika Tedarik Süresi
- 8 Weeks
- Collectoremitter Saturation Voltage
- 1.7V
- Kılıf / Paket
- 26-PowerDIP Module (1.024, 26.00mm)
- Max Current Rating
- 10A
- Supply Currentmax Isup
- 3.65mA
- Terminal Pozisyonu
- DUAL
- HTS Kodu
- 8541.29.00.95
- Max Supply Voltage
- 16.5V
- Weight
- 16.712g
- Qualification Status
- Not Qualified
- JESD-609 Kodu
- e3
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Tip
- IGBT
- Max Power Dissipation
- 34W
- Genişlik
- 23.5mm
- Montaj Tipi
- Through Hole
- Terminal Sayısı
- 26
