Volume pricing
- 1+ pcs$29.17
- 10+ pcs$27.51
- 100+ pcs$25.96
- 500+ pcs$24.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Min. Çalışma Sıcaklığı
- -40°C
- Parça Durumu
- Active
- Collector Emitter Voltage Vceo
- 2.1V
- Terminal Sayısı
- 34
- Genişlik
- 33mm
- Montaj Tipi
- Through Hole
- Additional Feature
- CONTROL SUPPLY VOLTAGE(VCC)= 15V
- Temperature Grade
- AUTOMOTIVE
- Tip
- IGBT
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Weight
- 32.58g
- Supply Voltagemax Vsup
- 400V
- Terminal Pozisyonu
- DUAL
- Max Current Rating
- 75A
- Kılıf / Paket
- 34-PowerDIP Module (1.480, 37.60mm)
- Reach Svhc
- No SVHC
- Fabrika Tedarik Süresi
- 7 Weeks
- Voltage Isolation
- 2500Vrms
- Output Currentmax
- 150A
- Seri
- Motion SPM® 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 80mm
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Kurşunsuz Kodu
- yes
- Min Breakdown Voltage
- 600V
- Maks. Çalışma Sıcaklığı
- 150°C
- Montaj
- Through Hole
- Jesd30 Code
- R-XDMA-T34
- Yayın Yılı
- 2014
- RoHS Durumu
- ROHS3 Compliant
- Maks. Oturma Yüksekliği
- 9.2mm
- Fonksiyon Sayısı
- 1
- Configuration
- 3 Phase
- Besleme Gerilimi
- 300V
