Specifications
- Average Rectified Current
- 8A
- Max Reverse Voltage Dc
- 600V
- Recovery Time
- 30 ns
- Montaj Tipi
- Through Hole
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Min. Çalışma Sıcaklığı
- -65°C
- Forward Current
- 8A
- Reach Svhc
- No SVHC
- Diode Element Material
- SILICON
- Parça Durumu
- Obsolete
- Output Currentmax
- 8A
- Akım Değeri
- 8A
- Current Reverse Leakage Vr
- 100μA @ 600V
- Additional Feature
- FREE WHEELING DIODE, SNUBBER DIODE
- Peak Reverse Current
- 100μA
- Maks. Çalışma Sıcaklığı
- 150°C
- Kurşunsuz
- Lead Free
- Voltage Forward Vf Max If
- 2.4V @ 8A
- Number Of Phases
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Forward Voltage
- 2.4V
- Reverse Recovery Time
- 30 ns
- Diode Configuration
- 1 Pair Common Cathode
- Terminal Pozisyonu
- SINGLE
- Case Connection
- ISOLATED
- Voltage Rated Dc
- 600V
- Terminal Sayısı
- 3
- Diode Type
- Standard
- Max Surge Current
- 80A
- Continuous Drain Current Id
- 8A
- Operating Temperature Junction
- -65°C~150°C
- Applications
- VERY FAST SOFT RECOVERY
- Number Of Elements
- 2
- HTS Kodu
- 8541.10.00.80
- Reverse Voltage
- 600V
- Peak Nonrepetitive Surge Current
- 80A
- Max Repetitive Reverse Voltage Vrrm
- 600V
- Kılıf / Paket
- TO-220-3 Full Pack
- Power Dissipation
- 26W
- ECCN Kodu
- EAR99
