Specifications
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Montaj Tipi
- Through Hole
- Kurşunsuz Kodu
- yes
- Yükseklik
- 26.7mm
- Ambalaj
- Tube
- Max Reverse Voltage Dc
- 600V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reach Svhc
- No SVHC
- Terminal Sayısı
- 3
- Terminal Pozisyonu
- SINGLE
- Additional Feature
- FREEWHEELING DIODE, HIGH RELIABILITY
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2004
- Reverse Recovery Time
- 90 ns
- Terminal Kaplaması
- Tin (Sn)
- Max Forward Surge Current Ifsm
- 180A
- Applications
- ULTRA FAST RECOVERY
- HTS Kodu
- 8541.10.00.80
- Diode Type
- Standard
- Radyasyon Dayanımı
- No
- Voltage Forward Vf Max If
- 2.2V @ 30A
- Max Repetitive Reverse Voltage Vrrm
- 600V
- Average Rectified Current
- 30A
- Montaj
- Through Hole
- Diode Element Material
- SILICON
- Pin Sayısı
- 3
- JESD-609 Kodu
- e3
- Maks. Çalışma Sıcaklığı
- 150°C
- Number Of Phases
- 1
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Operating Temperature Junction
- -65°C~150°C
- Fabrika Tedarik Süresi
- 4 Weeks
- Case Connection
- ISOLATED
- Forward Voltage
- 2.2V
- Peak Nonrepetitive Surge Current
- 180A
- Current Reverse Leakage Vr
- 100μA @ 600V
- Number Of Elements
- 2
- Weight
- 6.962g
- Min. Çalışma Sıcaklığı
- -65°C
- RoHS Durumu
- ROHS3 Compliant
